Siv-D

We designed Siv-D with a concept of Simple, Fashionable and imaginative. Also with excellent craftwork and strict standard for materials. Appearance with rich texture.

We use special Micro reflector and anti-glare cover, UGR<12, comfortable and soft lights distribution by different beam angle for Direct 75° & Indirect 140°.Suitable for four desks of 0.8*1.6m offering uniform lighting on eye areas with assembled base. Typical value up to 120lm/W with flicker freely.

Separate control for Direct & Indirect lights. Support smart functions like Motion sensor, Daylight sensor with constant lux for eyes area, Tunable white.Profile aluminum, steel, and PC as main materials. Easy to move and put on the edge of desk based on DIY. No need professional electrician.

TECHNICAL DATA
System power: 150 W
Luminous flux of luminaire: 18000 lm
Colour temperature: 4000 K / 3000 K / 3000~6000 K Tunable
UGR: <12

Colour Rendering Index: CRI >80

Colour consistency SDCM: <3

Maintained luminous flux: L80 (B10) 50'000 h
Protection class: Protection class I
Ingress Protection (IP): IP20
Filter options
  • System Power

    150W
  • Surface Finish

    Black White Silver
  • Colour temperature

    3000K 4000K 3000K~6000K
  • Beam Angle

    ↑140°/80°↓ ↑140°/50°↓
  • UGR

    <12
  • Sensor

    Daylight & Motion sensor
Item NO.System PowerSurface FinishColour temperatureBeam AngleUGRSensorDownloads
20.010.36018150WSilver3000K~6000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.34017150WSilver4000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.33016150WSilver3000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.26015150WWhite3000K~6000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.24014150WWhite4000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.23013150WWhite3000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.16012150WBlack3000K~6000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.14011150WBlack4000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.13010150WBlack3000K↑140°/50°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.36009150WSilver3000K~6000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.34008150WSilver4000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.33007150WSilver3000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.26006150WWhite3000K~6000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.24005150WWhite4000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.23004150WWhite3000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.16003150WBlack3000K~6000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.14002150WBlack4000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
20.010.13001150WBlack3000K↑140°/80°↓<12Daylight & Motion sensorPDFIMIESLDTSIZE
